Diamond Micron Powder For Electroplated Tools RME
Characteristics: This grade of diamond micron powder and diamond polishing powder using premium grade MBD diamond powder as the raw materials,modification of the diamond surface with special chemical acid treatment, regular crystal shape, concentrated particle size distribution (PSD) to avoid Nickel nodule during electroplating.
Applications: Customized for Electroplated diamond tools.
Available Size: 0-0.25 micron to 40-60 micron
Diamond Micron Powder Particle Size Comparison Chart
| Chinese Standard (um) | Product Designation Size (um) | Factory Workshop Standard |
Equivalent US Mesh Size |
| 0-0.25 | 0-0.25 | W0.25 | 60000# |
| 0-0.5 | 0-0.4 | W0.5 | 28000# |
| 0-1 | 0-0.8 | W1 | 15000# |
| 0.5-1 | 0.4-0.8 | — | — |
| 0.5-1.5 | 0.4-1.2 | W1.5 | 13000# |
| 0-2 | 0-1.6 | W2.5 | — |
| 1.5-3 | 1.2-2.3 | W3.5 | 8000# |
| 2-4 | 1.6-3.1 | — | 5000# |
| 2.5-5 | 1.9-3.9 | W5 | 4000# |
| 3-6 | 2.3-4.7 | W7 | 3000# |
| 4-8 | 3.1-6.2 | — | 2500# |
| 5-10 | 3.9-7.8 | W10 | 2000# |
| 6-12 | 4.7-9.3 | — | 1500# |
| 8-12 | 6.2-9.3 | W14 | 1200# |
| 10-20 | 7.8-15.5 | W20 | 800# |
| 12-22 | 9.3-17.1 | — | 700# |
| 20-30 | 15.5-23.3 | — | 600# |
| 22-36 | 17.1-27.9 | W28 | — |
| 36-54 | 27.9-41.9 | W40 | 400# |
