CNGO CNMO Solid CBN Insert
The dimple at the center of our solid cbn insert is processed from laser machining machine.
Dimple solid cbn insert can enhance the clampping strength when fitting on the tool holder,it can prevent insert from moving and dropping off during turning and cutting process,dimpe size and shape can be available up on drawing and request.This CBN insert can be used for roller turning,automotive brakedisk turning and bearing turning applications.
CNMO120404 CNMO120408 CNMO120412 CNMO120416 CNMO120712 CNMO120716
CNGO120404 CNGO120408 CNGO120412 CNGO120416 CNGO120712 CNGO120716
Edge preparation can be S01020 S02020 S05020 and other chamfer according to request.
CNGO CNGX CBN Insert
| ISO | L | Φ IC | S | r |
| CNGO 120404 | 12.7 | 12.7 | 4.76 | 0.4 |
| CNGO 120408 | 12.7 | 12.7 | 4.76 | 0.8 |
| CNGO 120412 | 12.7 | 12.7 | 4.76 | 1.2 |
| CNGO 120604 | 12.7 | 12.7 | 6.35 | 0.4 |
| CNGO 120608 | 12.7 | 12.7 | 6.35 | 0.8 |
| CNGO 120612 | 12.7 | 12.7 | 6.35 | 1.2 |
| CNGO 120708 | 12.7 | 12.7 | 7.94 | 0.8 |
| CNGO 120712 | 12.7 | 12.7 | 7.94 | 1.2 |
| CNGO 120716 | 12.7 | 12.7 | 7.94 | 1.2 |
| CNGO 120804 | 12 | 12.7 | 7.94 | 0.4 |
| CNGO 120806 | 12 | 12.7 | 7.94 | 0.4 |
